CASE wheel loaders deliver best-in-class horsepower and massive torque to deliver power to every work cycle. Four power modes let operators match available engine power to the job while saving fuel. Wheel Loader with stronger and faster hydraulics deliver superior productivity and performance.
THE PERFECT EQUIPMENT FOR:
WHEEL LOADERS FEATURES
With no EGR or particulate filter
The engine was developed and manufactured by our award-winning sister company FPT Industrial, which produces over 500,000 engines per year and powers world record winners.
The in-house Wheel Loaders design leverages advanced technologies developed for commercial vehicles and agriculture and introduces specific tailored solutions for off-road applications. The engine is designed to offer both fuel efficiency and reliability with plenty of power available.
The air intake flow is increased by a turbocharger with air-to-air cooling.
The multiple injection delivers best-in-class high torque performance at low rpms.
No EGR valve is used: 100% fresh air is taken for combustion without DPF and no extra cooling system is needed.
Our engine technology is so reliable that it is trusted by the French Sea Rescue service for their boats: what better guarantee could you wish for?
AXLES AND DIFFERENTIALS
CASE heavy-duty axles
The heavy-duty axles are tougher, bigger and easier to service thanks to the 3-piece housing design. Wet multiple disc brakes, made of resistant sintered bronze, are located in each wheel hub. Our heavy-duty axles are engineered to support L5 or solid tyres for very abrasive environments. Solid tyres can be factory fitted.
A higher value results from:
20-30% lower tyre wear because of no slippage between the wheels;
Reduced fuel consumption because there is no friction in the differential;
Reduced downtime for maintenance because of fewer moving components with open differentials.
100% auto lock differential
With open differentials, no friction is applied to reduce wheel slip. As a result, there is less tyre wear and lower energy losses. With the 100% Auto-lock, 100% of the available torque is transmitted to the wheels to provide maximum tractive effort.
CASE COOLING CUBE
CASE cooling cube
The unique design of the CASE cooling cube, with five radiators mounted to form a cube instead of overlapping, ensures a constant flow of fresh and clean air from the sides and from the top, to maintain constant fluid temperatures. The cube structure provides easy access to radiators for more effective cleaning and serviceability: additional cleaning can also be easily done manually, with separate access to each radiator.
COMFORTABLE AND SAFE CAB
Wider and well-protected cab:
Our reinforced cab guarantees protection against rollover (ROPS) and falling objects (FOPS).
Our cab is also certified P2 level according to European Standards EN143, which means that 94% of airborne particles are filtered. When working in particularly tough conditions, additional pressurization and particle filtration can be fitted.
On Waste Handler models windshield guards, provide protection from falling pieces of solid waste.
The CASE Wheel Loader Cab is 2.06 m³ and 1.64 m wide: it is the widest cab in the industry.
The air suspended seat features a high back design and lumbar adjustment, a saving grace during long working days. It includes seat heaters which warm up cold winter mornings.
Wide glazed surfaces and curved engine hood
You’ll feel more confident and work faster with the great all-round visibility provided by the very low shape of the curved rear hood and the ample glazed surfaces.
